型号 |
滚筒中心距A(mm) |
皮带宽度 |
650 |
800 |
1000 |
1200 |
1400 |
1600 |
1800 |
DEL
D=190mm
E=500mm
G=重量 |
1300 |
L=1820mm
C=1320mm
G=540kg |
L=1820mm
C=1520mm
G=640kg |
|
|
|
|
|
2000 |
L=2520mm
C=1320mm
G=600kg |
L=2520mm
C=1520mm
G=740kg |
L=2520mm
C=1720mm
G=880kg |
|
|
|
|
2700 |
L=3220mm
C=1320mm
G=760kg |
L=3220mm
C=1520mm
G=800kg |
L=3220mm
C=1720mm
G=940kg |
|
|
|
|
3500 |
L=4020mm
C=1320mm
G=700kg |
L=4020mm
C=1520mm
G=910kg |
L=4020mm
C=1720mm
G=1100kg |
|
|
|
|
4000 |
L=4520mm
C=1320mm
G=810kg |
L=4520mm
C=1520mm
G=960g |
L=4520mm
C=1720mm
G=1110kg |
|
|
|
|
4500 |
L=5020mm
C=1320mm
G=8500kg |
L=5020mm
C=1520mm
G=1000kg |
L=5020mm
C=1720mm
G=1150kg |
|
|
|
|
5000 |
L=5520mm
C=1320mm
G=900kg |
L=5520mm
C=1520mm
G=1050kg |
L=5520mm
C=1720mm
G=1200kg |
|
|
|
|
DEM
D=320mm
E=500mm |
1500 |
|
|
L=2190mm
C=1860mm
G=1200kg |
L=2190mm
C=2110mm
G=1400kg |
|
|
|
2000 |
|
|
L=2690mm
C=1860mm
G=1300kg |
L=2690mm
C=2110mm
G=1500kg |
L=2690mm
C=2310mm
G=1600kg |
|
|
2700 |
|
|
L=2690mm
C=1860mm
G=1400kg |
L=3390mm
C=2110mm
G=1600kg |
L=4190mm
C=2310mm
G=1800kg |
|
|
3500 |
|
|
L=4190mm
C=1860mm
G=1600kg |
L=4190mm
C=2110mm
G=1700kg |
L=4690mm
C=2310mm
G=1900kg |
L=4190mm
C=2510mm
G=1900kg |
L=4190mm
C=2710mm
G=2000kg |
4000 |
|
|
L=4690mm
C=1860mm
G=1600kg |
L=4690mm
C=2110mm
G=1800kg |
L=5190mm
C=2310mm
G=1900kg |
L=4690mm
C=2510mm
G=2000kg |
L=4690mm
C=2710mm
G=2100kg |
4500 |
|
|
L=5190mm
C=1860mm
G=1700kg |
L=5190mm
C=2110mm
G=1900kg |
L=5190mm
C=2310mm
G=2000kg |
L=5190mm
C=2510mm
G=2100kg |
L=5190mm
C=2710mm
G=2200kg |
5000 |
|
|
L=5690mm
C=1860mm
G=1800kg |
L=5690mm
C=2110mm
G=2100kg |
L=5600mm
C=2310mm
G=2100kg |
L=5690mm
C=2510mm
G=2200kg |
L=5690mm
C=2710mm
G=2300 |
